Fixed hydraulic lifting platform

Contact me:

Product introduction
Online consultation
The fixed hydraulic lifting platform is mainly a closed or meshed well surrounded by buildings or light steel structures and uses a hydraulically driven cylinder to lift the platform.

The hydraulic system of the fixed hydraulic lifting platform product is generally equipped with safety protection devices such as anti-fall, overload, and power failure. The rail-type external power unit, the table top entrance and exit use hanging chains or cross bars, guardrails and lifting platform operation warning lights or warning bells, and safety switches that shut down the lifting platform circuit when the door is opened. It greatly facilitates the operator to control multiple points on each working layer, and operate in jog or safe mode.

The product has a solid structure, large load capacity, stable lifting, simple and convenient installation and maintenance. It is an economical and practical ideal cargo transportation equipment to replace elevators between low floors. According to the installation environment and use requirements of the lifting platform, different fixed hydraulic lifts and different optional configurations can be selected to complete the task of lifting items and achieve better use results.


Fixed   hydraulic lifting platform
Art.NoDescription typeLoad CapacityPlatformOwn heightLift HeightMax HeightPowerVoltage
KgL*WMM(MM)(MM)(MM)kwV
WEL0604001SJG0.3-0.5300900*3502005007000.75380V
WEL0604002SJG0.5-0.5500900*3802005007001.1380V
WEL0604003SJG1-0.9710001500*100023097012001.5380V
WEL0604004SJG1-1.510002500*2000340150018402.2380V
WEL0604005SJG1.5-1.215002000*1500350120015502.2380V
WEL0604006SJG2-120001600*1000300100013002.2380V
WEL0604007SJG2-1.620002500*2000360160019603380V
WEL0604008SJG3-130001600*1200360100013603380V
WEL0604009SJG4-1.240002400*1200400120016004380V
WEL0604010SJG5-1.550002600*2000480150019804380V
WEL0604011SJG6-1.260002000*2000480120016804380V
WEL0604012SJG8-180001600*1600500100015004380V
WEL0604013SJG10-1.6100003500*2200680160022805.5380V
WEL0604014SJG15-1.6150003500*2200780160023807.5380V
WEL0604015SJG20-1.8200006000*2500720180025207.5380V
WEL0604016SJG30-1.6300007000*30008801600248011380V


Submit
Material list & certificate
Company introduction

Nasheng Import & Export (Shandong) Co., Ltd. is mainly engaged in the research, development, production and sales of off-road forklifts, reach forklifts, electric forklifts, etc., and has developed outstanding new products in various industries. From production and manufacturing technology, product quality, after-sales service and other aspects, Nasheng Import & Export is outstanding in the domestic engineering machinery industry.
"Nasheng" forklifts are widely used throughout the country and in countries and regions such as Europe and Southeast Asia, providing ideal and reliable engineering machinery for engineering tasks of companies of different sizes. Whether in cities or villages, our products meet the different needs of customers and have won unanimous praise.
