Product introduction
Online consultation
The fixed hydraulic loading ramp is a special auxiliary equipment for fast loading and unloading of goods. Its height adjustment function builds a bridge between the truck and the cargo platform in the warehouse. Forklifts and other handling vehicles can directly enter the truck to load and unload goods in batches through it. Only one person is needed to achieve fast loading and unloading of goods. It enables enterprises to reduce a lot of labor, improve work efficiency, and obtain greater economic benefits.

1. Full hydraulic drive, easy operation and reliable operation.

2. The lip plate and the platform are connected by a full-length shaft, with high strength and good reliability.

3. Imported seals are used to ensure that the hydraulic system has excellent sealing performance.

4. Imported integral modular hydraulic station is used, with good sealing and long service life.

5. The high-strength "U"-shaped beam design can ensure that it will not deform under high load and long-term operation.

6. The table top is made of anti-slip patterned steel plate with good anti-slip performance.

7. Anti-rolling skirts are set on both sides to prevent toes from entering the platform and causing accidental injuries.

8. Safety support rods are provided to ensure that maintenance personnel enter the internal maintenance of the loading ramp


Fixed hydraulic ramp
Art.NoDescription   typeCapacityPlatformFlapLift   HeightVoltage   PowerConcrete   Pit
KgL*W（MM）（MM）（MM）kw（MM）
WEL0606001   DCQ6-0.5560002000*20002000*400Floating   300   Floating down 250380V/0.752080*2040*600
WEL0606002   DCQ6-0.760002000*25002000*400Floating   400   Floating down 300380V/0.752080*2540*600
WEL0606003   DCQ8-0.5580002000*20002000*400Floating   300  Floating down 250380V/0.752080*2040*600
WEL0606004   DCQ8-0.780002000*25002000*400Floating   400   Floating down 300380V/0.752080*2540*600
WEL0606005   DCQ10-0.55100002000*20002000*400Floating   300  Floating down 250380V/0.752080*2040*600
WEL0606006   DCQ10-0.7100002000*25002000*400Floating   400 Floating down 300380V/0.752080*2540*600
WEL0606007   DCQ15-0.55150002000*20002000*400Floating   300  Floating down 250380V/0.752080*2040*600
WEL0606008   DCQ15-0.7150002000*25002000*400Floating   400  Floating down 300380V/0.752080*2540*600
WEL0606009   DCQ20-0.55200002000*20002000*400Floating   300   Floating down 250380V/0.752080*2040*600
WEL0606010   DCQ20-0.7200002000*25002000*400Floating   400  Floating down 300380V/0.752080*2540*600
